Alpha+ Industrial Differential 4P 40A 300Ma Class A Superimmunized 6Ka
Brand: RETELEC
Reference: EPR4A040300
Description
Alpha+ Industrial Differential 4P 40A 300Ma Class A Superimmunized 6Ka. Diferential switch. Class A (detects alternating and continuous leakage currents). 4 Poles. 300 I?n (mA). 40 Int (A). Packaging unit: 1. Operating voltage: 415/240V AC. International standard EN/IEC61008-1. Cutting power: 10000A. Local state signage. Circuit marker window. Compatible with EPR and EPB series. Connection capacity up to 35 mm2. Dimensions: 1 module per pole (18mm).
Details
Three-phase Differential Switch for 4P DIN rail with a current intensity of 40 Amps, and a Breaking Power of 6kA.
Sensitivity: 300 mA. UNE-EN 61008-1.
Dimensions: 70 mm
Allows the use of pin and fork type connection combs
International regulations EN/IEC61008-1
Use: Domestic, tertiary and industrial.
